07 4637 9511- Lever Lock Bracket: This solid 10-position bracket features a quick-release lever lock and reinforced composite material that resists flexing, warping, and UV damage.
- Telescoping Tiller: Get easy, comfortable, intuitive operation of your trolling motor with the six-inch telescoping tiller.
- 5 Fwd/3 Rev Speed Settings: Five speed settings for forward and three speed settings for reverse.
- Power Prop: For 3-1/4″ motor diameters, this prop delivers extra power to push throw heavy vegetation. Includes prop pin, nut and washer.
- Indestructible Composite Shaft — Guaranteed for Life: At the core of your Minn Kota trolling motor is an indestructable composite shaft. It’s a Minn Kota exclusive, and we guarantee it for life.
- Cool, Quiet Power: Every Minn Kota lower unit runs cool to extend trolling motor life, and stays quiet.
| Transom to Waterline | Recommended Shaft Length |
|---|---|
| Up to 10" | 30" |
| 10" to 16" | 36" |
| 16" to 22" | 42" |
| Over 22" | Consult Factory |
| Total Boat Weight (LB) | Boat Length | Recommended Minimum Thrust | Voltage |
|---|---|---|---|
| 1,599 or less | 14' | 30 - 40 | 12v |
| 1,600 - 2,599 | 16' - 17' | 40 - 55 | 12v |
| 2,600 - 3,599 | 17' - 18' | 70 - 80 | 24V |
| 3,600 - 4,599 | 18' - 19' | 80 - 90 | 24V |
| 4,600 - 5,599 | 20' - 23' | 112 - 115 | 36V |
| 5,600 - 9,999 | 24' - 28' | 112 - 115 | 36V |
| 10,000 - 15,000 | 28' - 35' | 115 | 36V |
Endura 30 lb / Hand – 30"
| Code / SKU | 601110 |
|---|---|
| Max thrust | 30 lb |
| Voltage | 12V |
| Shaft length | 30" |
| Speeds | 5 forward / 3 reverse |
| Mounting | Transom-mount |
| Motor style | Hand-steer |
| For use in | Freshwater |
| Bracket | Lever lock, 10-position, reinforced composite |
| Tiller | 6" telescoping tiller |
| Shaft | Indestructible composite (lifetime guarantee) |
| Propeller | Power Prop (for 3-1/4" motor diameter) |
| Digital Maximizer | No |
| Battery meter | No |
| Power trim | No |
| Warranty | Two-year |
Endura 40 lb / Hand – 36"
| Code / SKU | 601120 |
|---|---|
| Max thrust | 40 lb |
| Voltage | 12V |
| Shaft length | 36" |
| Speeds | 5 forward / 3 reverse |
| Mounting | Transom-mount |
| Motor style | Hand-steer |
| For use in | Freshwater |
| Bracket | Lever lock, 10-position, reinforced composite |
| Tiller | 6" telescoping tiller |
| Shaft | Indestructible composite (lifetime guarantee) |
| Propeller | Power Prop (for 3-1/4" motor diameter) |
| Digital Maximizer | No |
| Battery meter | No |
| Power trim | No |
| Warranty | Two-year |
